Год начала выпуска: 1986
Регион: Европа
SPECIFICATIONS
Type Stereo multiband radio
cassette recorder
Power source Batteries, DC 9 V (R20PX6)
CS-W220E.Z
AC 220 V, 50—60 Hz
CS-W220K
AC 240 V, 50—60 Hz
Output 6.6 W maximum (3.3W + 3.3W)
Power consumption
CS-W220E,Z
12W
CS-W220K
14 W Speakers 100 mm cone type X 2
Tape Recorder Section
Built-in microphone Electret condenser microphone
Tape speed 4.8 cm/sec (1-7/8 ips)
Recording system AC bias
Erasing system Magnet erase
Recording time 90 minutes (C-90 cassette,
both directions)
Frequency response
NORMAL tape: 40—12,000 Hz
Cr02 tape: 40—14,000 Hz
METAL tape: 40—16,000 Hz
Radio Section
Frequency ranges
FM: 87.5—108 MHz
SW: 5.9—18 MHz
MW: 530—1,605 kHz
LW: 150—285 kHz
Antennas Whip antenna for FM and SW
Ferrite bar antenna for MW and LW
Dimensions (WXHXD) 492X151X120.5 mm
Weight 2.5 kg
Accessories AC power cord X 1
The specifications and external appearance of this set are subject to change without prior notice.
|
