Год начала выпуска: 1983
Регион: Азия
Power Supply:
AC: 110V to 127V, 200 to 220V, 230 to 250V, 50/60 Hz
DC: 12V ["C" cell (IEC R14) x 8 or equivalent] Car: Use 12V car battery adaptor
Power (mains) consumption: 25W
Speakers: 10cm, 2.8 ohms x 2
2 cm, 500 ohms x 4
Output: 30W P.M.P. (AC operation)
5 W/CH (10% THD DC)
Dimensions: 174(H) x 636(W) x 169.5(D) mm
Weights: 6.7 kg (with batteries)
RADIO SECTIONS
Circuit System:
FM/SW2/SW1/AM 4-band superheterodyne
Tuning Range:
FM: 88 to 108 MHz
SW2: 7.0 to 22.0 MHz
SW1: 2.3 to 7.0 MHz
AM: 530 to 1605 kHz Antenna (Aerials): FM/SW2: Telescopic antenna (aerial)
SW1/AM: Built-in ferrite-core antenna (aerial)
TAPE RECORDER SECTION
Tape: Cassette tape
Tape Speed: 4.75 cm/s
Recording System: AC bias ... TAPE [2]
Erasing System: AC erase ... TAPE [2]
Playback Frequency Range: 40 to 12,000 Hz (Normal tape)
Input Sensitivity and Impedance: External microphone: 2 mV, 10 kohms
Line in: 400 mV, 50 kohms Output Level and Load Impedance: Headphones: 8 to 100 ohms
External speaker: 2.8 to 8 ohms
|
