JVC RC-S 22 L
В мою коллекцию    Сравнить

SPECIFICATIONS
Frequency range:

FM      88 —108 MHz
MW     540 -1600 kHz

LW      150-350 kHz

SW1     5.95-6.2 MHz

SW2    7.1 - 7.3 MHz

SW3    9.5-9.8 MHz

SW4    11.7-12.0 MHz

SW5    15.1 - 15.45 MHz

SW6    17.7-17.9 MHz
Antennas:                         Telescopic antenna for FM
and SW1 ~ SW6 Ferrite core antenna for MW& LW
Track system:                  2-track, monaural
Wow and flutter:             0.2 % (WRMS)
Rewind and fast-forward time:       Approx. 105 sec. (C-60 cassette)
Speaker:                            8 cm (3-3/16") x 1, 8Ω
Power output:                  1.1 W max. (8 Ω.)
                                        750 mW per channel at 10%THD
Jacks:                                 Earphone x1,  MICxI,
Ext. DC (6 V) x 1
Power supply:                  DC 4.5 V (3 "R6" size
cells)
Dimensions:                     243.5(W) x 104(H) x71.5(D) mm
