SPECIFICATIONS
<RADIO>
Radio Frequency Range: FM; 88-108MHz
MW; 525-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7-22 MHz
Frequency Range:
50-12,000 Hz (with normal tape)
50- 14,000Hz (with CrO2 tape)
Recording System: DC bias,
Erasing system Magnet erase
Track System: 4-track 2-channel stereo recording and playback
Tape speed: 4.8 cm/s
Wow&Flutter 0.06%
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD and
REWIND TIME: Approx. 110 seconds with C-60 cassette tape
Power Requirement:
<GENERAL>
Power Requirement:
AC; 100-110/115-127/200-220/230-250V , 50/60 Hz
Power consumption; 18W
Battery; 12 V (eight "UM-1", D size batteries)
Car Battery; with optional car battery cord RP-952
Power Output: 12W (6Wx2)...(DC max)
Speaker: Woofer;14cm PM dynamic speaker 3Ω
Tweeter; 3cm PM dynamic speaker(4Ω)
Jacks:
Input;
MIC; sensitivity 0.45 mV/applicable microphone impedance
200-600 Ohm (recommended microphone RP-8135)
DC in 13.2V
LINE IN; sensitivity 450 mV/47 kOhm.
OTHERS;
REMOTE; for start and stop at hand
Output; LINE OUT sensitivity 0.36V
EXT SP; 3 Ohm
HEADPHONES; 8 Ohm
Dimensions: (WxHxD)467x292x131 mm
Weight: 5.2 kg without batteries
(not included)
