Год начала выпуска: 1980
Регион: Европа
Power Supply: AC: 110V to 127V, 200 to 220V, 230 to 250V, 50/60 Hz
DC: 13.5V ["D" cell x 9 or equivalent Car: Use 12V car battery adaptor
Speakers: 16cm x 2, 2x5 cm
Output: 2x8 W RMS (AC operation)
Dimensions: 318(H) x 556(W) x 173(D) mm
Weights: 8.0kg (with batteries)
RADIO SECTIONS
Circuit System: FM/MW/SW/LW 4-band superheterodyne
TAPE RECORDER SECTION
Tape: Cassette tape
Tape Speed: 4.75 cm/s
Playback Frequency Range: 50 to 12,000 Hz (Normal tape)
50 to 14,000 Hz (Chrome tape)
50 to 15000 Hz (Metal tape)
Input Sensitivity and Impedance: External microphone: 2 mV, 10 kohms
Line in: 400 mV, 50 kohms Output Level and Load Impedance:
Headphones: 8 to 100 ohms
Noise Reduction Dolby
|
