Год начала выпуска: 1981
Регион: Япония
Specifications
DIMENSIONS: 56.7 x 28.7 x 16.8 cm.
Weight approx. 7 kg
TUNER SECTION
Frequency Ranges : FM 76 - 108 MHz
MW 530 -1600 kHz
Tape recorder section
Track system : 4-Track 2-channel stereo
Frequency response : 30-16,000Hz (with metal tape)
30-15,000Hz (with chrome tape)
30-14,000Hz (with normal tape)
Wow & flutter : 0.12% (WRMS)
S/N ratio : 52dB (Line out: Metal)
Rewind time : Within 95sec. (C-60 cassette)
Fast forward time : Within 95sec. (C-60 cassette)
Speakers: 16 cm (6-1/2") x 2
5 cm (2") x 2
AMPLIFIER SECTION
PowerOutput : Max. 3.5W (1.5W + 1.5W)
Input Jacks
Phono
Output Jacks Headphones (8 - 32 Ohms)
Ext. Speaker x 2 (8 Ohms)x 2 (3 mV, 47 kOhms)
POWER CONSUMPTION: 20 W
SEMICONDUCTORS Transistors : 23
ICs : 14
POWER SOURCE DC : 15 V, 10 "D", "R20"cells or
equivalent
AC : 100 V., 50/60 cs.
|
