RADIO FRQUENCY RANGE: FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7 MHz
SW2; 7-22 MHz
POWER REQUIREMENT: AC; 110-115/115-127/200-220/230-250 V. 50/60 Hz
Power consumption; 11 W
Battery; 9 V (six UM-2, "C" size batteries)
Car battery; with optional car adaptor RP-917
POWER OUTPUT: 16 W (8 Wx2)...PMPO
8 W (4 Wx2)...RMS max.
SPEAKER: Woofer 10 cmx2
Tweeter 1.5 cmx2
FRQUENCY RANGE: 60-12,000 Hz (with Normal tape)
60-13,000 Hz (with Metal tape)
RECORDING SYSTEM: AC bias, Magnet erase
JACKS: INPUT; MIC; sensitivity 0.25 mV/applicable microphone
impedance 200 Ω-600Ω (recommended microphone RP-8135)
LINE IN; sensitivity 200 mV/50 kΩ DC IN; 9 V
OUTPUT; LINE OUT; sensitivity 0.42 V/10 kΩ
EXT SP; 3-8Ω
HEADPHONES; 32Ω
DIMENSIONS: 441 mm (W)x 141 mm (H)X105 mm (D)
WEIGHT: 2.8 kg without batteries
subject to change without notice.
