SPECIFICATIONS
Radio Section
Frequency Range: FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7.0-22.0 MHz
Power Requirement: AC; 110-127/200-220/230-250 V, 50/60 Hz
Power consumption; 37 W
Battery; 12 V (eight UM-1, "D" size batteries)
Power Output: 15W(7.5Wx2)...RMS(max.)
Speakers: Woofer; (12cm PM Dynamic Speaker 3Ω) x 2
Tweeter; (2cmx4cm PM Dynamic Speaker 1.4kΩ)x2
Tape Deck Section Tape1
Frequency Range: 70-14,000 Hz(with normal tape)
70-16,000 Hz(with Metal tape)
Recording System: AC bias, AC erase
Tape Speed: 4.8cm/s
Track System: 4-track 2-channel stereo recording and playback
Tape Deck Section Tape2
Frequency Range: 70-14,000 Hz(with normal tape)
70-16,000 Hz(with Metal tape)
Tape Speed: 4.8cm/s
Track System: 4-track 2-channel stereo playback
Input; MIX MIC; sensitivity 1.6 mV/applicable microphone impedance
200 -600Ω (Ø3.5mm) LINE IN; sensitivity 250 mV/47 kΩ
Output; EXTSP; 2.7-8ΩØ3.5mm
HEADPHONES; 32ΩØ3.5mm
Dimensions:
Total Size 581 x 187x173 mm(WxHxD)
Main Unit; 322x187x173 mm(WxHxD)
Speaker Box; 133x187x144 mm(WxHxD)
Weight: 4.9 kg without batteries
