Год начала выпуска: 1980
Регион: Азия
SPECIFICATIONS
Power Requirement: AC; 100 - 110/115 - 127/200 - 220/ 230-250V 50/60 Hz
Battery; 9V (six "D" size dry batteries) (Panasonic UM-1 or equivalent)
Power Consumption: 16W
Power Output: 8W (4W x 2)...RMS (max.)
Frequency Range: 50- 12.000Hz (with normal tape)
Recording System: AC bias. Magnet erase
Program Time: 1 hour with C-60 cassette tape
Track System: 4-track 2-channel stereo recording and playback
Input: MIC; sensitivity 0.25mV/applicable microphone impedance 200 - 600Ω
LINE IN; sensitivity 250mV/47kΩ over
Output: LINE OUT; sensitivity 0.36V load
impedance 6.8 kΩ under EXT SP; 3-8Ω HEADPHONE; 8 Ω
Speaker: Woofer; 12cm (5") PM Dynamic speaker (3Ω)
Tweeter; 3cm (1½") ceramic speaker (200 Ω)
Radio
Frequency Range: FM; 88-108MHz
MW; 530-1600kHz
SW1 2.3 - 7.0MHz
SW2 7.0 -22.0MHz
Intermediate Frequency: FM; 10.7MHz
MW; 455kHz
Sensitivity: FM; 1.7μV/50mW output
MW; 120μ V/m/50mW output
Dimensions: 47cm(W) x 25.5cm(H) x 14.6cm(D)
(18 ½(W) * 10"(D) x 5¾(D)
Weight: 4.1 kg (9 lb. 1 oz.) without batteries
|
