Год начала выпуска: 1970
Регион: Европа
Specifications:
Output: 2 x 4 watts RMS
Tape:
Philips-type compact cassette tape
Tape speed: 4.75 cm/s ± 2%
Frequency response:
60 Hz to 10000 Hz
S/N ratio:
≥ 45dB
Wow and flutter: 0.3% (WRMS)
Input sensitivity and input impedance:
Ext. Mic; 600 ohms
Mixing mic; 600 ohms
Line in; 150mV \1,5M Ω
Output level and loaded impedance:
Headphones; 8 ohms to 25 ohms
External speaker; 4 ohms to 8 ohms
Line out; 0.7V/50k ohms
Power source; AC 110\127 V \ 220V\ 245 V, 50/60 Hz
Dimensions:
Width; 352 mm
Depth; 215 mm
Height; 73 mm
Weight (without batteries): 5 kg
|
