История фирмы AKAI началась в июле 1929 г. Фирма выпускала множество различных устройств включая электромузыкальные инструменты и медицинскую технику. В начале 90-х годов была продана, в связи с появившимися финансовыми проблемами.
Подробнее о производителе
Глоссарий аббревиатур
|
|
|
Год начала выпуска: 1983
Регион: Америка
Specifications
Track System....................4 Track 2 Channel Stereo System
Tape.............................Philips Type Cassette
Tape Speed......................4.76 cm/s ± 1.5% (1 -7/8 ips. ± 1.0%)
Heads...........................Erase Head x 1
Super GX head for recording x1
Super GX head for playback x1
Motors...........................FG servo D.C. motor for direct capstan drive x 1
D.C. motor for reel drive x 1
Wow & Flutter....................0.08% WTD (DIN), 0.028% WRMS
Tape Winding Time..............90 sec. using a C-60 cassette tape
Frequency Response............Normal: 25 to 17,000 Hz ±3 dB (-20 VU)
Cr02: 25 to 18,000 Hz ±3 dB (-20VU)
Metal; 25 to 19,000 Hz ±3 dB (-20 VU)
Signal to Noise Ratio.............Metal: Better than 60 dB (measured via tape with peak recording level)
Dolby B-type NR switch ON: Improves up to 5 dB at 1 kHz, 10 dB above 5 kHz
Dolby C-type NR switch ON: Improves up to 15 dB at 500 Hz, 20dB at 1 kHz to 10 kHz
Harmonic Distortion.............1 kHz, 3rd harmonic distortion Metal: Less than 0.8%
Input............................Line: 70 mV (input impedance: 47 kohms)
Output...........................Line: 410 mV at 0 VU
Required load impedance: more than 20 kohms
Phone: 1.3mW/8ohms at 0 VU
Power Requirements.............120V, 60 Hz for USA and Canada
220V, 50 Hz for Europe except UK
240V, 50 Hz for UK and Australia
110V/120V/220V/240V, 50/60 Hz switchable for other countries
Dimensions......................440(W) x 118(H) x309(D)mm
Weight...........................8.6 kg (12.8 lbs)
STANDARD ACCESSORY Connection Cords............................................................1 set |
|
|
|
|
