SHARP 15 1912 ., . "". 1915 . " " , . 1923 . . , Haykawa Metal Works, - Sharp Corparation.

1925 . , , . , . , SHARP. , SHARP .

1926 . , . 1951 . , 1952 . RCA. SHARP TV3-14T.

1952 . . 1961 . .





Sharp GF-7474 Z



: 1982


SPECIFICATIONS
Power source : AC 110V-127 V and 220V ~ 240V, 50/60Hz
DC 9V (UM/SUM-1, R 20, HP-2 or D type 6, )
SPEAKER Speakers: 12cm woofer 2
Ceramic type tweeter 2

Output power:
PMPO;16W (8W + 8W) (AC operation)
MPO; 12W (6W + 6W) (AC operation)
RMS; 5.8W (2.9W + 2.9W) (DCoperation, 10% distortion)
Semiconductors: 6 Is 9 transistors
21 diodes 7 LEDs
Dimensions: Width; 500mm
Height; 225mm
Depth; 120mm
Weight: 4.0 kg without batteries

TAPE RECORDER
Tape: Compact cassette tape
Frequency response: 50Hz -10,000Hz
Signal/noise ratio: 50 dB
Wow and flutter: 0.1% (WRMS)
Input impedance: external mic;600 ohms
Line in 82 kohms
Loaded impedance: Headphones; 8 ohms 25 ohms
External speakers; 2.4 ohms 8 ohms

RADIO
Frequency range: AM; 525 kHz - 1605 kHz
SW1; 2.3MHz- 7.3MHz
SW2; 7.3 MHz-22 MHz
FM; 87.6MHz-108 MHz





rahim : 28.01.2016 19:11:23
u have gf 7474
rahim : 09.02.2016 09:53:25
u have gf 7474
Alex : 25.03.2016 20:25:29
I have this Sharp GF 7474, in good condition)
