SANYO " "-, . 1947 . , 40- , 50- . , , . SANYO -, .

SANYO 100 . : "" . 1980 . SANYO . -152 .

SANYO : -; ; (LSI Chip), : : , .





Sanyo M 9996 K



: 1979


SPECIFICATIONS Sanyo M 9996 K
Recording system AC bias, 4-track stereo
Erasing system AC erase, 2-track
Tape speed 4.75 cm/sec (1-7/8 i.p.s.)
Rewind and fast forward time Rewind: 1 min. 35 sec. (C—60)
Fast forward: 1 min. 50 sec. (C-60)
Frequency range FM: 87.5 - 108MHz
SW2: 7.0 - 22MHz
SW1: 2.3 - 7.0MHz
MW: 530- 1,605kHz
Terminal impedance MIC: 3.3 kohms (0.3mV)
PHONO: (MM) 47 kohms (3mV)
(CERAMIC) 1 Mohms (300mV)
LINE IN: 470 kohms (50mV)
LINE OUT: 1 kohm (0.775V)
EXT SP: 2.5 - 8 ohms
PHONES: 8 ohms
Frequency response 40 - 12,000Hz (NORMAL)
40 - 15,000Hz (CrO2)
Signal to noise ratio 52 dB (Normal)
Output power 10000mW x 2 maximum (music power)
Power source DC: 12V "D" (UM-1) x 8
12V Car battery adaptor
AC: 120/200/240V, 50/60Hz 30W
Dimensions 582(W) x 173(D) x 245(H) mm

Weight Approx. 8 kg including batteries

:
