Год начала выпуска: 1985
Регион: Америка
Specifications
Cassette Tape Used
Normal C-30, C-60, C-90, C-120
Chrome C-46, С-60,С-90
(playback only)
Metal
C-46, С-60
(playback only)
Tape Speed: 4.8 cm/sec.
Track System: Four-track, two-channel stereo-
phonic
Recording System: AC bias
Erasing System: AC erasing
Frequency Response: Normal 70 Hz to 14 kHz
Receiving Frequency
FM: 88 MHz to 108 MHz
MW: 525 kHz to 1605 kHz
Intermediate Frequency
FM: 10.7 MHz
AM: 455 kHz
Antenna FM, telescopic
antenna AM: ferrite-core antenna
Speakers 100 mm (dia.) dynamic x 2
15 mm (dia.) piezo-electric type x 2
Jacks [MIC] jack x 2, Impedance 200
ohm to 2k ohm
[PHONES] jack x 1
Power Supply AC 120 V
60 Hz
DC 9 V [ IEK-1 (R14) "С" cellx6]
Power Consumption 16 W
Dimensions (W) 442 mm x (H) 140.5 mm x(D) 118 mm
Weight 2.3 kg (without batteries)
Specifications are subject to change for improvement.
|
