Год начала выпуска: 1978
Регион: Азия
SPECIFICATIONS
Type: 4 Band Stereo Radio Cassette Recorder
Frequency Ranges
AJ-500FS: FM: 87.6-108 MHz
MW: 525-1,605 kHz
SW1: 3.9-12 MHz
SW2: 12-26 MHz
AJ-500FL: FM: 87.6-107 MHz
LW: 150-290 kHz
MW: 525-1,605 kHz
SW: 4.9-12 MHz
Antennas: Rod Antenna for FM, SW and SW2,
Bands, Built-in Bar Antena for LW, MW
and SW1, Bands
External Antenna Terminal for all Bands
Speaker: 2 Way 4 speaker
Woofer: 12cm x 2
Tweeter: 4cm x 2
Max. Power Output: 3.8 W x 2
Tape: Philips Type Cassette Tape
Track System: 4 Track 2 Channel Stereo System
Monitor System: Variable Monitor System
F. F. & Rewind Time Within 120 sec. (Using a C-60 Cassette Tape)
Wow & Flutter: 0.1% (WRMS)
Frequency Response: Normal: 50 to 12,000 Hz
Distortion: Less than 1.5%
Signal to Noise Ratio: Normal: 50 dB
Power Requirements: 120V/60 Hz for Canada
220V/50 Hz for Europe except U.K.
240V/50 Hz for U.K. & Australia
110-120V/220-240V, 50/60 Hz for Other Countries
DC 9V 6 "D" size batteries
Power consumption 20W
Dimensions: 440 x 260 x 162 mm
(W) x (H) x (D) Weight: 5 kg
|
