Ôèðìà áûëà îñíîâàíà â 1910 ã. ìîëîäûì èíæåíåðîì Íàìèõåé Îäàèðà â êà÷åñòâå ðåìîíòíîé ìàñòåðñêîé ýëåêòðîîáîðóäîâàíèÿ ïðè êîìïàíèè ïî äîáû÷å ìåäè. Íàçâàíèå ôèðìû ñîñòîèò èç êîìáèíàöèè äâóõ èåðîãëèôîâ"Õè"è " Òà÷è", îçíà÷àþùèõ Ñîëíöå è Âîñõîä, îëèöåòâîðÿþùèõ ñàìó ßïîíèþ - ñòðàíó âûñî÷àéøèõ òåõíîëîãèé.
Ïîäðîáíåå î ïðîèçâîäèòåëå
Ãëîññàðèé àááðåâèàòóð
|
|
|
Ãîä íà÷àëà âûïóñêà: 1980
Ðåãèîí: Àçèÿ
Specification
GENERAL SECTION
Semi-conductors: IC's: 9
Transistors: 24
Diodes: 16
LED: 5
Power(Mains) Supply: AC:100-110V/115-127V/200-220V/230-250V 50/60Hz
DC:12V(IEC R20x8)
Car: Use car battery adaptor
Power (Mains) Consumption: 24 W
Dimensions: 294(W) x 504(H) x 167(D) mm
Weight: 6.4 kg (with batteries)
Power output: 5W/CH (Max.), 5W/CH (THD 10%)
Speaker: 16 cm, 2.8 ohms x 2
5 cm, 4 ohms x 2
TUNER SECTION
Circuit System: FM/SW1/MW/SW2 4-band
superheterodyne
Tuning Range: FM: 87.5 to 108 MHz
SW1: 2.3 to 7.0 MHz
MW: 530 to 1605 kHz
SW2: 7.0 to 22.0 MHz
Sensitivity: FM: 10 dB (pra.) 2dB (max.)
SW: 25 dB (pra.) 20 dB (max.)
MW: 42 dB (pra.) 30 dB (max.)
Intermediate Frequency: FM: 10.7 MHz
SW/MW: 468 kHz
Antennas (Aerials): FM/SW: Telescopic antenna or
External antenna MW/LW: Ferrite-core antenna
TAPE RECORDER
Tape: Cassette tape (C-30, 60, 90)
Tape Speed: 4.75 cm/s
Recording System: AC bias, 57 kHz
Erasing System: AC erasing
Frequency Response: Normal: 50 ~ 10,000 Hz
Cr02: 50 ~ 13,000 Hz
Metal: 50 ~ 15,000 Hz
S/N
(Signal to Noise Ratio): 45 dB (Dolby NR OFF)
Cross Talk: 60 dB
Erase Ratio: 65 dB
Input Sensitivity
and Impedance: Microphone: 0.4 mV, 10 ohms
Phone: 3 mV . 50 Kohms
Record/PlaybacklDIN): 6mV, 12 Kohms
Output Level and Impedance: Record/Playback (DIN): 775 mV, 5 Kohms
Ext. speaker: 3.2 ohms
Fast Forward or
Rewinding Time: 110 sec (Using C-60)
Distortion: 2%
Motor: DC micromotor |
|
|
|
|
