Год начала выпуска: 1980
Регион: Азия
SPECIFICATIONS
<RADIO>
Radio Frequency Range: FM; 88-108 MHz
SW2; 7.0-22 MHz
MW; 525-1605 kHz
SW1 2.3-7.0 MHz
Frequency Range:
100-10000 Hz (with normal tape)
Recording System: DC bias,
Erasing system Magnet erase
Track System: 4-track 2-channel stereo recording and playback
Tape speed: 4.8 cm/s
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD and
REWIND TIME: Approx. 110 seconds with C-60 cassette tape
Power Requirement:
<GENERAL>
Power Requirement:
AC; 100-115/115-127/200-220/230-250 V, 50/60 Hz
Power consumption; 16W
Battery; 9 V (six UM-1D" size batteries)
Car Battery; with optional car battery cord RP-9550
Power Output: 7W (3.5Wx2)...RMS(max)
10W(5Wx2) PMPO
Speaker: Woofer 12cm PM dynamic speaker(3Ω)
Tweeter 3cm
ceramic speaker(200Ω)
Jacks:
Input;
MIC; sensitivity 0.25 mV/applicable microphone impedance
200-600 Ohm (recommended microphone RP-8135)
LINE IN; sensitivity 250 mV/47 kOhm.
Output; LINE OUT sensitivity 0.36 v load impedance
6.8kΩ under
EXT SP; 3 -8 Ohm
HEADPHONES; 8 Ohm
Dimensions: (WxHxD)434x228x131 mm
Weight: 2.8 kg without batteries
(not included)
|
