Год начала выпуска: 1978
Регион: Япония
Type Stereo 2 band radio cassette recorder
Circuitry 46 transistors, 17diodes, 4 ICs, 3 LED's, 1 FET
Power source Batteries, DC 9V (UM-1 x 6)
AC 100 V \ 50-60 Hz
Car battery (thru car adaptor)
Output 9.8W maximum (4.9W + 4.9W)
Power consumption 17 W
Speakers 160 mm round (2)
52 mm round (2)
Tape Recorder Section
Built-in microphones Electret condenser microphones
Tape speed 4.8 cm/sec
Recording system AC bias
Erasing system AC erase
Recording time 90 minutes (C-90 cassette, both directions)
Frequency response Normal tape: 50-12,000 Hz
Cr02 tape: 50-14,000 Hz
Signal to noise ratio 54 dB
Wow and flutter 0.07% (WRMS)
Radio Section
Frequency ranges FM: 76-90 MHz
AM: 525-1605 kHz
Antennas Whip antenna for FM
Ferrite bar antenna for AM
External antenna terminals for FM
Dimensions (WxHxD) 490 x 370 x 130 (mm)
Weight 7 kg (including batteries)
Accessories AC power cord 1
Cassette tape 1
Batteries (Super UM-1) 6
Head cleaning stick 1
The specifications and external appearance of this set are subject to change without prior notice.
|
