Год начала выпуска: 1981
Регион: Япония
SPECIFICATIONS
Radio section
Frequency range FM 76-108 MHz
AM 530-1,605 kHz
Antennas FM: Telescopic antenna
AM: Built-in ferrite bar antenna
Tape recorder section and general
Recording system 4-track 2-channel stereo
Fast winding time Approx. 1 min. 30 sec. Cassette C-60
Frequency response 30-14,000 Hz (NORMAL)
30-16,000 Hz (Cr02)
30-17,000 Hz (METAL)
S/N 52 dB
Wow and flutter 0.075% (WRMS)
Speakers Two-way.
Approx. 20 cm (7 3/4 inches) dia. woofer
Approx. 5 cm (2 inches) dia. tweeter
Dimensions: Width; 612mm
Height; 319mm
Depth; 141mm
Weight: 8.5kg without batteries
Output power: MPO; 20W (10W + 10W) (AC operation)
RMS; 15W (7.5W + 7.5W) (DC operation)
Power requirements 100V ac ,
50\ 60 Hz
12 V dc, eight batteries size D (IEC designation R20)
Power consumption 18 W ac
|
