Matsushita Electric Industrial , Ltd. (MEI), Panasonic, National, Technics Quasar, , .





National Panasonic RF-1150 LB GX600



: 1975


SPECIFICATIONS
Radio Frequency Range;
FM; 87.5-108MHz
LW; 145~355 kHz (2060m845m)
MW; 520~1610kHz (577m
186m)
SW1; 3.9~12MHz (76.9
25m) ..
SW2; 12~30MHz (25
10m)
Intermediate Frequency: FM; 10.7 MHz
AM (MW\LW&SW); 455kHz
Sensitivity: FM: 2.0μV/50mW output
LW; 50μV/m/50mW output
MW; 10μV/m/50mW output
SW1; 2
μV/m/50mW output
SW2; 3μV/50mW output

Power Requirement; AC; 110~125/220-240V 50/60Hz
Battery; 6V (Four "D" Size Flashlight Batteries)
(National UM-1 or equivalent)

Power Consumption: 8W(AC only)

Power Output: 3.5W (max.)

Speaker: 16cm(6½") PM Dynamic Speaker 8Ω

Impedance; FM EXT.ANT ….75Ω
DIN jack
PHONO....500kΩ
REC OUT....80kΩ

Earphone jack; .........8Ω

Dimensions: 246mm(Wide)x237mm(High)x100(Deep) mm

Weight: 2.1kg without batteries
