Год начала выпуска: 1984
Регион: Япония
SPECIFICATIONS
RADIO FREQUENCY RANGE: FM; 76-90 MHz
AM; 530-1605 kHz
FM,TV 1-3ch
TV 4-12ch
POWER REQUIREMENT: AC; 100 V, 50/60 Hz
Power consumption; 11 W Battery; 9 V (6 UM-2, "C" size batteries)
POWER OUTPUT:
8 W(4Wx2)...RMS(max.)
SPEAKERS:
Woofer; 10 cm PM dynamic speaker 3Ω
Tweeter; 1.5 cm speaker 200Ω
FREQUENCY RANGE:
70-8000 Hz (with normal tape,CrO2)
60-8000 Hz (with Metal tape playback only)
RECORDING SYSTEM: AC bias, AC erase
TAPE SPEED: 4.8cm/s
TRACK SYSTEM: 4-track 2-channel stereo recording and playback
JACKS:
INPUT; MIC; sensitivity 0.26 mV/applicable microphone impedance
200Ohm-600Ohm. (recommended microphone RP-V305)
LINE IN; sensitivity 200 mV/47 kΩ
OUTPUT;
LINE OUT; sensitivity 420 mV/2.2 kΩ
EXT SP; 3-8Ω.
HEADPHONES; 32Ω
OTHERS; DC IN; 13.2 V
AC IN
DIMENSIONS: 459 mm x 132mm x 116 mm
(W) x (H) x (D)
WEIGHT: 2.8 kg without batteries
Specifications are subject to change without notice. |
