Год начала выпуска: 1980
Регион: Япония
SPECIFICATIONS
Type Stereo multiband radio cassette recorder
Circuitry
56 transistors, 26 diodes, 9 ICs, 7 LEDs, 1 FET
Power source Batteries,DC 12 V (UM-1 x 8)
AC 100 V 50/60 Hz
Car battery (thru car adaptor)
Output 10(5 W + 5 W)(EIAJ,DC)
Power consumption 20W
Speakers 160 mm cone (2)
50 mm dome (2)
Tape Recorder Section
Built-in microphones Electret condenser microphones
Tape speed 4.8 cm/sec
Recording system AC bias
Erasing system AC erase
Recording time 90 minutes (C-90 cassette, both directions)
Frequency response(-20 VU)
LH tape: 50—125000 Hz ±3dB
Cr02 tape: 50—13 000 Hz ±3dB
METAL tape: 50—14000 Hz ±3dB
Signal-to-noise ratio 54 dB (LH tape, Dolby NR OFF) (PEAK LEVEL) 65 dB
(METAL tape, Dolby NR ON)
Wow and flutter 0.07% (WRMS)
Radio Section
Frequency ranges FM: 76—90 MHz
AM: 525—1605 kHz
Antennas Whip antenna for Ferrite bar antenna for AM
External antenna terminals for FM
Dimensions (WxHxD) 557 x 332 x 170 (mm)
Weight 8.4 kg
Accessories
AC power cord 1
Cassette tape 1
Batteries 8
The specifications and external appearance of this set are subject to change without prior notice.
|
