Год начала выпуска: 1979
Регион: Япония
SPECIFICATIONS
RADIO FREQUENCY RANGE: AM; 525~1605 kHz
FM; 76~108 MHz
POWER REQUIREMENT: AC; 100V, 50—60 Hz.
Power consumption; 11W Battery; 9 V (six-UM-1 R20 size dry batteries)
Car/boat battery; with optional car/boat adaptor RP-917
POWER OUTPUT: 3.5 W (DC max.)
SPEAKER: 10cm PM dynamic speaker 3.2Ω
5 cm 500 Ω PM dynamic speaker
FREQUENCY RANGE: 100~ 9,000 Hz (with normal tape)
100~10,000 Hz (with CrO2)
100~10,000 Hz (FeCr)
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8 cm/s (1 7\8 ips)
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD AND REWIND TIME: Approx. 90seconds with C-60 cassette tape
TRACK SYSTEM: 2-track 1-channel monaural recording and playback
INPUT: MIC; sensitivity 0.25 mV/applicable, microphone impedance 200~600ohms
(recommended microphone WM-2213)
LINE; sensitivity 63 mV/470 kohms
DC IN;
OUTPUT:
EXT SP; 3~8Ω HEADPHONES; 8Ω
DIMENSIONS: 350(W) x287(H) x117(D)mm
WEIGHT: 3.2 kg without batteries
Specifications are subject to change without notice.
|
