TEAC A-170 S





TECHNICAL DATA
Track System: 4 track, 2 channel stereo system
Tape: Philips type cassette
Tape Speed: 4.8 cm/s
Wow & Flutter: Less than 0.09% WRMS,
Frequency Response: 30 to 11,000 Hz +3 dB using LN tape
30 to 14,000 Hz ±3 dB using Cr02/FeCr tape
tape Distortion (1,000 Hz 0 VU): Less than 1.3% using LN tape
Less than 1.3% using LH tape
Less than 2.0% using Cr02 (SA) tape

Better than 50 dB using LH tape
Better than 52 dB using Cr02 tape
(measured via tape with peak recording level)
Dolby NR switch ON: Improves up to 10 dB above 5 kHz
Erase Ratio: Better than 65 dB
Bias Frequency: 100 kHz

Motor: (1): D.C. servo motor with F.G. voltage control
Power Consumptions: 8W
Power Requirements: 117V/60 Hz for U.S.A. & Canada
220V/50 Hz for European Countries except U.K.
240V/50 Hz for U.K. & Australia
110/120/220/240V (Switchable), 50/60 Hz for the other countries

Dimensions: 430(W) x 166(H) x 255(D) mm
Weight: 4.5 kg
