Type: 2626
Power output: RMS DIN 2 x 25 watts RMS / 4 ohms
2 x 20 watts RMS / 8 ohms
2 x 40 watts music / 4 ohms
2 x 25 watts music / 8 ohms
Speaker impedance 4 ohms
Harmonic distortion < 0.1%
Intermodulation < 0.15%
Frequency range +/- 1.5 dB 20 - 30,000 Hz
Damping factor > 35
Phono, inputs 2.2 mV / 47 kohms
Overload margin 80 mV
Signal-to-noise ratio > 60 dB
Tape, inputs 400 mV / 100 kohms
Signal-to-noise ratio > 60 dB
Channel separation 1000 Hz > 56 dB
Channel separation 250 - 10,000 Hz > 40 dB
Tape, outputs (norm. input phono) 30 mV / 100 kohms
Headphones 14 V / 220 ohms
Bass control at 40 Hz +/- 12 dB
Treble control at 12,500 Hz +/- 12 dB
Balance control +/- 60 dB Tuner:
FM range 87.5 - 108 MHz
LW range 147 - 350 kHz
MW range 520 - 1610 kHz
Tape Recorder:
Compact cassette: C60 - C90
Wow and flutter < +/- 0.20 %
Speed deviation < +/- 1%
Fast forward and rewind C60 85 sec
Frequency range, chrom 30 - 14,000 Hz
Signal-to-noise ratio chrom > 56 dB
Signal-to-noise ratio chrom with Dolby > 63 dB
Erasure > 70 dB
Microphone input 0.1 mV / 10 kohms
Power supply:
110 - 130 - 220 - 240 V
Power consumption 160 W
Dimensions W x H x D: 68 x 9 x 27cm
Weight 11 kg
Connections: gramophone, extra tape, headphone
