Год начала выпуска: 1984
Регион: Европа
Specifications:
Track System: 4 track, 2 channel stereo system
Tape: Philips type cassette
Tape Speed: 4.76 cm/s ±1% (1-7/8 ips ±1% )
Heads: 2 head for recording/for playback x1
Erase head x1
Motors: DC servo motor for direct capstan drive x1
DC motor for reel drive x1
Wow & Flutter: Less than 0.11% WTD Peak
Less than 0.06% WTD RMS,
Power Requirements: 110/120/220/240V (Switchable), 50/60 Hz for the other
countries
Power Consumption: 23 Watts
Tape winding time: 90sec using a C-60 cassette tape
Frequency Response: 20 to 20,000 Hz ±3 dB (recording level -20VU)
Signal to Noise Ratio: Dolby B-type NR switch ON: (70μs ,ZX tape) Better than 62 dB
Dolby C-type NR switch ON: (70μs ,ZX tape) Better than 68 dB
Total Harmonic Distortion: Less than 1,0% (400Hz, 0 dB ,ZX, EX 2 tape)
Input Line: 50 mV (Input impedance 35kohms)
Output Line: 0.5 mV at 0 VU
. Required load impedance: More than 2.2 kohms
Phone: 2,2 mV/8 ohms at 0 VU
Dimensions: 430(W) x 110(H) x 250(D) mm
Weight: 5.5 kg
|
