Nakamichi (. 中道) . 中道 — , 1948 . 19731993 Nakamichi - (. 中道仁郎) . 1993 , , , , 1990-. Nakamichi Grande Holdings, Niro Nakamichi. Nakamichi .




Nakamichi BX-125



: 1985


Specifications:
Track System: 4 track, 2 channel stereo system
Tape: Philips type cassette
Tape Speed: 4.76 cm/s ±1% (1-7/8 ips 1% )
Heads: 2 head for recording/for playback x1
Erase head x1
Motors: DCservomotor for direct capstan drive x1
DC motor for reel drive x1
Wow & Flutter: Less than0.11% WTD Peak
Less than0.06% WTD RMS,
Power Requirements: 100V (Switchable), 50/60 Hz
Power Consumption: 17 Watts
Tape winding time: 90sec using a C-60 cassette tape

Frequency Response: 20to 20,000 Hz3 dB (recording level -20VU)



Signal to Noise Ratio: Dolby B-type NR switch ON:(70μs ,ZX tape)Better than 62 dB
Dolby C-type NR switch ON: (70μs ,ZX tape)Better than 68 dB
Total Harmonic Distortion: Less than 1,0% (400Hz,0 dB ,ZX, EX2 tape)


Input Line: 50 mV(Input impedance 35kohms)
Output Line:0.5 mV at 0 VU
. Required load impedance: More than 2.2 kohms
Phone: 2,2 mV/8 ohms at 0 VU


Dimensions: 430(W) x 100(H) x 250(D) mm

Weight: 5.0 kg
