Nakamichi (. 中道) . 中道 — , 1948 . 19731993 Nakamichi - (. 中道仁郎) . 1993 , , , , 1990-. Nakamichi Grande Holdings, Niro Nakamichi. Nakamichi .




Nakamichi CR-7





Specifications:
Track System: 4 track, 2 channel stereo system
Tape: Philips type cassette
Tape Speed: 4.76 cm/s ±1% (1-7/8 ips 1% )
Heads: 3 ( head for record head x 1,playback head x1,Erase head x1)
Motors: /Tape Transport/
FGservobrushless,slotless, coreless DD motor ( capstan drive) x1
DCmotor ( reel drive) x1
/Mechanism/
DCmotor ( cam drive) x1
DC motor ( playback head azimuth control) x1
Wow & Flutter: Less than0.048% WTD Peak
Less than0.027% WTD RMS,
Power Requirements: 100V/220V/240V/ , 50/60 Hz
Power Consumption: 55 Watts
Tape winding time: 80sec using a C-60 cassette tape

Frequency Response: 20to 20,000 Hz2 dB (recording level -20VU)
18to 21,000 Hz3 dB (recording level -20VU)


Signal to Noise Ratio: Dolby B-type NR switch ON:(70μs ,ZX tape)Better than 66 dB
Dolby C-type NR switch ON: (70μs ,ZX tape)Better than 72 dB
Total Harmonic Distortion: Less than 0,8% (400Hz,0 dB ,ZX tape)
Less than 1,0% (400Hz,0 dB ,SX, EX2 tape)

Input Line: 50 mV(Input impedance 40kohms)
Output Line:1V at 0 VU
. Required load impedance: More than 2.2 kohms
Phone: 12 mV/8 ohms at 0 VU


Dimensions: 435(W) x 135(H) x 306D) mm

Weight: 9.0 kg

Remote Control Unit RM-7C
System: Infrared pulse system
DC 3V(1.5V x 2)
Dimensions: 57(W) x 175(H) x 19(D) mm

Weight: 140 g
