Superscope CRS-3504 n



: 1981


Specifications for Superscope CRS- 3504 n
Tuner SectionSuperscope CRS- 3504 n
MW 525-1605 kHz
FM 88- 108 MHz
SW 6.0- 18.0 MHz
LW 150-370 kHz

Separation FM: more 30dB


Amplifier Section
Power output
2.6 w x 2(1kHz 10% Dist)
Speakers:
Frequency response: 100-16,000Hz
Speaker complements Woofer 12cm
Tweeter 4cm
Crossover frequency 8,500Hz
Nominal impedance 2.5 Ohms
Cassette Deck Section
Tape speed Standart 4.8cm\sec
Heads 2 heads system Superhard Permalloy
THD 3%
Wow & flutter: 0.25 %
Motor DC servo controlled motor x 1
Frequency response: 60-10000Hz


Power source:
batt UM-1(D size) x6 DC9V
AC 110/220V 50Hz 18W
Dimensions : 561(W) x 129(D) x 237(H) mm
Weight : 6.7kg

:
