Год начала выпуска: 1987
Регион: Америка
GENERAL SPECIFICATIONS
Power supply:
AC: 120V 60 Hz
DC: 12V ["D" cell (IEC R20) x 8 or equivalent]
for memory back-up 3V IEC R6
Power consumption: 18W
Speakers: 100mm, 8 ohms x4
Dimensions: 210(H) x 579(W) x 177(D) mm
Weight: 5.1 kg (with batteries)
RADIO SECTION
Circuit system: FM/AM 2-band superheterodyne
Tuning range: FM: 87.5 to 107.9 MHz
MW: 530 to 1610 kHz
Antenna (aerials): FM: Telescopic antenna (aerial)
AM: Built-in ferrite-core antenna (aerial)
TAPE RECORDER SECTION
Tape: Cassette tape
Tape speed: 4.75 cm/s
Recording system: AC bias ...
Erasing system: Magnet erase ...
Playback frequency range:
60 to 12,000 Hz (Normal tape)
JACK:
External microphone: 2 mV, 6 kohms
AUX/CD: 500 mV, 50 kohms
Output level and load impedance:
Headphones: 8 to 100 ohms
DBSS speakers jack x 2
Specifications are subject to change for performance improvement without notice.
|
