Год начала выпуска: 1987
Регион: Европа
GENERAL SPECIFICATIONS
Power supply:
AC: 220V 50 Hz
DC: 12V ["D" cell (IEC R20) x 8 or equivalent]
for memory back-up 3V IEC R6
Power consumption: 30W
Speakers: 100mm dynamic x 2
100mm woofer x 2
Dimensions: 210(H) x 614(W) x 174(D) mm
Weight: 5.7 kg (with batteries)
RADIO SECTION
Circuit system: FM/AM 2-band superheterodyne
Tuning range: FM: 87.5 - 108 MHz
SW: 5.95 -15.6 MHz
LW: 146- 281 kHz
MW: 531 to 1602kHz
Antenna (aerials): FM: Telescopic antenna (aerial)
AM: Built-in ferrite-core antenna (aerial)
TAPE RECORDER SECTION
Tape: Cassette tape
Tape speed: 4.75 cm/s
Recording system: AC bias ...
Erasing system: Magnet erase ...
Playback frequency range:
60 to 12,000 Hz (Normal tape)
JACK:
External microphone: 2 mV, 6 kohms
AUX/CD: 500 mV, 50 kohms
Output level and load impedance:
Headphones: 8 to 100 ohms
DBSS speakers jack x 2
Specifications are subject to change for performance improvement without notice.
|
