SPECIFICATIONS
<RADIO>
Radio Frequency Range:
FM; 87.5-108 MHz
MW; 520-1610 kHz
SW1; 5.9-18 MHz
LW; 150-285 MHz
Frequency Range:
70-12,000 Hz
Recording System: DC bias,
Erasing system Magnet erase
Track System: 4-track 2-channel stereo recording and playback
Tape speed: 4.8 cm/s
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD and
REWIND TIME: Approx. 110 seconds with C-60 cassette tape
Power Requirement:
<GENERAL>
Power Requirement:
AC; 110-127/200-220/230-250V , 50/60 Hz
Power consumption; 30W (AC only)
Battery; 12 V (Eight "UM-1", D size batteries)
Car Battery; with optional car battery cord RP-9550
Power Output: 15W (7.5Wx2)…(RMS max)
Speaker: Woofer; 12cm PM Dynamic Speaker (3Ω)
Tweeter; 2cmx4cm Ceramic Speaker(1.5kΩ)
Jacks:
Input;
MIX MIC; sensitivity 5 mV/applicable microphone impedance
200-600 Ohm
LINE IN; sensitivity 300 mV/50 kΩ
Output;
EXT SP; 2.7- 8 Ω
HEADPHONES;32Ω(Ø3.5mm)
Dimensions: Total Size
(WxHxD) 637x199x162 mm
Main unit
344(W)x199(H)x162(D)
Speaker Box
151(W)x199(H) x133(D)
Weight: 5.0 kg without batteries
(not included)
