Год начала выпуска: 1991
Регион: Азия
■ SPECIFICATIONS (European model)
General:
Power Requirement: AC; 230-240 V, 50Hz
Battery; 15V (10 UM-1, R20/LR20 batteries)
Memory Back-up for Computer/Clock;
6V (4UM-3, R6/LR6 batteries)
Power Consumption: 57W (AC only)
Power Output: Woofer; 60W (30Wx2)...PMPO
Tweeter; 20W (10Wx2)...PMPO
Speaker: Woofer; 12cmx2PM Dynamic
speaker (2.7Ω)
Tweeter; 8cmx2PM Dynamic speaker (8Ω)
Input: MIX MIC;5mV/200~600Ω, ∅3.5
DC IN; 13.2V (12-15V) CD/AUX;316mV/47kΩ
Outputs: HEADPHONE; 32Ω, ∅3.5
SPEAKER; LOW; 2.7-8Ω HIGH; 8-16Ω
Dimensions: 641 (W) x 255(H) x 232(D)mm
Main unit; 313(W) x 255(H) x 232(D)mm
Speaker box; 174(W) x 254(H) x 188(D)mm
Weight: 8.4kg without batteries
Radio Section:
Frequency Range: FM; 87.5-108MHz
LW; 144~288kHz
MW; 522-1611 khz
Intermediate Frequency: FM; 10.7MHz
AM; 459 kHz
Sensitivity: FM; 2.0μv/50mW output
(-3dB Limit Sens.)
LW; 160μV/m/50mW output
MW; 140μV/m/50mW output
Tape Deck Section:
Frequency Range: 30-16,000 Hz (with normal tape)
30-17,000 Hz (with Cr02tape)
Recording System: AC bias, AC arese
Tape Speed: 4.8 cm/s
Monitor System: Variable sound monitor
Track System: 4-track 2-channel stereo recording and
playback
|
