SPECIFICATIONS
Radio Frequency Range: FM; 87.5-108 MHz
MW; 520-1610 kHz
SW1; 5.9-18 MHz
LW; 148.5-285 MHz
Power Requirement: AC; 220-240 V, 50 Hz
Power consumption; 20 W(AC only)
Battery; 9V (six UM-1, "D" size batteries)
Power Output: 10 W(5Wx2)...PMPO
8W(4Wx2)...RMS(max.)
Speakers: Woofer; (12cm PM dynamic speaker 3Ω) x 2
Tweeter; (2cmx4cm speaker 1.4Ω)x2
Frequency Range: 50-13.000 Hz(with normal tape)
Recording System: AC bias, Magnet erase
Tape Speed: 4.8cm/s
Track System: 4-track 2-channel stereo
Jacks:
LINE IN; sensitivity 200 mV/47 kom
Output; EXTSP; 2.7-8Ω
HEADPHONES; 32Ω
Dimensions: 559 x 194x154 mm(WxHxD)
Main unit; 314x194x154 mm(WxHxD)
Speaker box; 125x194x132 mm(WxHxD)
Weight: 3.8 kg without batteries
