Aiwa CA-W1



: 1982


SPECIFICATIONSCA-W10

Type Stereo 2 band radio

cassette recorder

Circuitry 70 transistors, 34 diodes,

13 ICs, 21LEDs

Power sourceBatteries, DC 13.5 V (UM-1 x 9)



AC 100 V

(switchable) 50—60 Hz,


Output 28 W maximum (14W +14 W)

Power consumption CA-W1 23W


Tape Recorder Section

Tape speed 4.8 cm/sec

Recording system BAC bias

Erasing system B AC erase

Recording time B60 minutes (C-60 Compact cassette, both directions)

Frequency responseLH tape: 3013,000 Hz,

Cr02tape: 3014,000 Hz

METAL tape: 3016,000 Hz

Signal-to-noise ratio 54 dB (LH tape)

Wow and flutter 0.045% (WRMS)


Radio Section

Frequency ranges FM: 76108 MHz

M: 5251 605 kHz


AntennasWhip antenna for FM

Ferrite bar antenna for M

External antenna terminals for FM

Speaker SectionSystem

Type2-way closed type

Using speakerWoofer 120 mmcone type

Tweeter 50 mm cone type

Impedance 8 ohm

Playback frequency range50~18,000Hz

Output sound pressure level 88 dB/W/m

Allowable maximum input 15 W

Maximum dimensions645(W)x250(H)x198(D)mm

Total weight10.7kg (incl. batteries)

Supplied accessoriesAC power cord 1

speaker cord 2


:
Aiwa CA-W10
