SPECIFICATIONS
Radio Frequency Range: FM; 65-107 MHz
MW; 520-1610 kHz
SW1; 5.9-18 MHz
LW; 150-285 MHz
Power Requirement: AC; 110-127/200-220/230-250 V, 50/60 Hz
\ Power consumption; 37 W
/240 V, 50 Hz \
\Power consumption; 33 W/ Battery; 12 V (eight UM-1, "D" size batteries)
Car battery; with optional car adaptor RP-952
Power Output: 40 W(20Wx2)...PMPO
15W(7.5Wx2)...RMS(max.)
Speakers: Woofer; (12cm PM dynamic speaker) x 2
Tweeter; (2cmx4cmspeaker)x2
Frequency Range: 50-12000 Hz
Recording System: AC bias, Magnet erase
Tape Speed: 4.8cm/s
Track System: 4-track 2-channel stereo
Jacks:
Input; MIX MIC; sensitivity 5.6 mV/applicable microphone impedance
200 om-600om (recommended microphone RP-V305)
LINE IN/CD; sensitivity 316 mV/47 kom Output; EXTSP; 2.7-8om
HEADPHONES; 320
Dimensions: 581 x 187x169 mm(WxHxD)
Main unit; 322x187x169 mm
Speakerbox; 136x187x147 mm
Weight: 4.4 kg without batteries
