Год начала выпуска: 1997
Регион: Европа
Radio Frequency range
FM 87.50-108.00 MHz (50kHz steps)
AM 522-1629 kHz ( 9kHz steps)
520-1630 kHz (10kHz steps)
CD player
Sampling frequency 44.1kHz
Decoding 16 bit linear
Beam source Semiconductor laser (wavelength 780 nm)
No. of channels 2 channel, stereo
Frequency response 20 Hz-20 kHz
Wow and flutter Less than possible measurement data
D/A converter MASH (1 bit DAC)
Tape recorder
Track system 4 track, 2 channel, stereo
Recording system AC bias
Erasing system AC erase
Monitor system Variable sound monitor
Frequency range
Normal 30-16000 Hz
Cr02 30-17000 Hz
General
Power requirement
AC 110-127V/230-240 V, 50 Hz,
Power consumption; 33 W
Battery 12 V (Eight UM-1, R20/LR20 batteries)
Memory back-up for computer/clock
6 V (Four UM-3, R6/LR6 batteries)
Power output 30 W(15Wx2 ) (DIN)
Jacks Input MIC; 2.5 mV (4.7 kΩ)
AUX; 200mV(47kΩ)
Output HEADPHONES; 32Ω Ø3.5 mm
CD OUT; 1.0V(CD 0dB)
Dimensions (WXHXD) (Top panel closed) 630x177x326mm
Weight 6.3kg without batteries
|
