Panasonic NV-333



: 1982


SPECIFICATIONS

NV-333-EG, E, EO
Power Source: 220 V only AC 50-60 Hz
Power Consumption: Approx. 36 watts
Television System; CCIR: 625 lines, 50 fields PAL colour signal
Video Recording System: 2 rotary heads, helical scanning system
Luminance: FM azimuth recording
Colour signal: converted subcarrier phase shift recording
Audio Track: 1 track
Tape Format: Tape width 12.7 mm high density tape
Tape Speed: 23.39 mm/s
Record/Playback Time: 240 min. with NV-E240
FF/REW Time: Less than 4,5 min. with NV-E180
Heads: Video: 2 rotary heads
Audio/Control: 1 stationary head
Erase: 1 full track erase
Input Level: Video: VIDEO IN connector (BNC) 1.0 Vp-p, 75 ohm unbalanced
Audio: LINE IN jack -20 dB, 50 kohm unbalanced
Output Level: Video: VIDEO OUT connector (BNC)1.0 Vp-p, 75 ohm unbalanced
Audio: LINE OUT jack -6 dB, 1 kohm unbalanced
RF Modulated UHF channel 36 (±4) 75 ohm unbalanced
Video Horizontal Resolution: Colour: more than 240 lines
Audio Frequency Response: 80 Hz-10 kHz
Signal-to-Noise Ratio: Video: more than 40 dB
Audio: more than 43 dB
Weight: 8.4 kg
Dimensions: 430 (W) x 125 (H) x 358 (D) mm
Accessory Supplied: 1 pc. DIN-DIN coaxial cable, VJA0176 or 0177
Optional Accessories: Remote control unit, NV-A33
Video cassette tape:
NV-E240 Approx. 344 m, 240 min.
NV-E180 Approx. 258 m, 180 min.
NV-E120 Approx. 174 m, 120 min.
NV-E90 Approx. 130 m, 90 min.
NV-E60 Approx. 88 m, 60 min.
NV-E30 Approx. 45 m, 30 min.
Video Camera
Weight and dimensions shown are approximate. Specifications are subject to change without notice.
