National RX-FW20 F



: 1986


SPECIFICATIONS
RADIO FREQUENCY RANGE: FM; 88-108 MHz
MW; 530-1605 kHz
SW1; 2.3-7.0 MHz
SW2; 7.0-22.0 MHz
POWER REQUIREMENT: AC; 110-127/200-220/230-250 V, 50/60HZ
Power consumption; 14 W (240 V, 50 Hz
Power consumption; 14 W)
Battery; 9 V (six UM-1, "D" size batteries)
Car battery; with optional car adaptor RP-917
POWER OUTPUT: 16 W(8 Wx2)...PMPO
8W(4Wx2)...RMS max.
SPEAKERS: Woofer; 10 cm PM dynamic speaker
Tweeter; 2.2 cm speaker
FREQUENCY RANGE: 60-13000 Hz
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8cm/s
TRACK SYSTEM: 4-track 2-channel stereo
JACKS:
INPUT; MIXING MIC; sensitivity 5 mV applicable microphone
impedance 200Ω-600Ω (recommended microphone RP-V305)
LINE IN; sensitivity 224 mV/47 k
Ω
OUTPUT; HEADPHONES; 32
Ω
DIMENSIONS:
(WxHxD) 492x135x118mm
WEIGHT: 2.7 kg without batteries
Design and Specifications are subject to change without notice.


:
Panasonic RX-FW20
Panasonic RX-FW 20 L
National RX-FW20 F black
