SPECIFICATIONS
RADIO FREQUENCY RANGE: FM; 88-108 MHz
AM; 525-1610 kHz
POWER REQUIREMENT: AC; 120 V, 60Hz with included AC adapter
RD-9448M (RD-9403MC for Canada)
Power consumption; 10 W (AC only)
Battery; 9 V (six UM-1, "D" size batteries)
Car battery; with optional car adaptor RP-917
POWER OUTPUT: 7W(3.5Wx2)...RMS max.
SPEAKERS: Woofer; 10 cm PM dynamic speaker(2.7Ω)
Tweeter; 2 cm Ceramic speaker(200Ω)
FREQUENCY RANGE: 70-13000 Hz
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8cm/s
TRACK SYSTEM: 4-track 2-channel stereo
JACKS:
INPUT; MIXING MIC; sensitivity 5 mV/ applicable microphone
impedance 200Ω-600Ω (recommended microphone WM-2298)Ø3.5mm
LINE IN; sensitivity 224 mV/47 k
