Specifications
Speakers : 1 2 cm (3.2 Ω)x2, 2 cmx2
Tuner section
Frequency ranges : FM 88 —108 MHz
AM 540- 1600 kHz
SW1 2.3-7 MHz
SW 2 7-22 MHz
Antennas : Telescopic antenna for FM & SW
Ferrite core antenna for AM & SW1
Tape recorder section
Track system : 4-Track 2-Channel stereo
Frequency response : 80—12,000 Hz
Wow & flutter :0.19% (WRMS)
S/N ratio : 54 dB (Normal tape)
Rewind time : Approx. 120 sec. (C-60 cassette)
Fast forward time : Approx. 120 sec. (C-60 cassette)
Amplifier section
Power output : 1.5 watts per channel, min. RMS, at 3.2 ohms from 150 Hz to
10kHz, with no more than 10 % total harmonic distortion (RC-770JW)
Max. 6 W (3 W + 3 W) at 3.2 Ω
2.2 W per channel at 10% THD
Input jacks : Mic x 2 (1 mV, 200 - 2 kΩ)
Output jacks : Headphone x 1
Power supply : DC 9 V (6 "D" batteries)
Car battery (DC 9 V)
AC 240/220/110 V, 50/60 Hz (RC-770JW)
AC 120V, 60 Hz (RC-770C)
Power consumption : 11 W (RC-770JW), 9 W (RC-770C)
Dimensions : 520(W) x 239(H) x 136(D) mm
(20-1/2"x9-1/2"x5-3/8")
Weight : Approx. 3.2 kg (7.0 lbs)
(without batteries)
Design and specifications subject to change without notice.
