Panasonic RX-C20



: 1985


■ SPECIFICATIONS
General:

Power Requirement: AC; 120-240 V, 50/60Hz with AC adapter

Battery; 12V (8 "C" size,batteries)

Power Consumption: 18W ( with AC adapter)

Power Output: 15W...RMS

14W ...MPO

Speaker:8cm PM Dynamic speaker (2.7Ω)


Input: MIX MIC;5mV/200~600
Ω, 3.5

DC IN; 13.2V CD/AUX;316mV/47k
Ω

Outputs: HEADPHONE; 32
Ω, ∅3.5

SPEAKER; 2.7-8
Ω ∅3.5


Dimensions: Total size

417 (W) x 113(H) x 170(D)mm

Main unit; 212(W) x 113(H) x 170(D)mm

Speaker box; 106(W) x 113(H) x 152(D)mm

Weight: 3.5kg without batteries
Radio Section:

Frequency Range: FM; 87.5-108MHz

AM; 520-1610 khz

Intermediate Frequency: FM; 10.7MHz

AM; 459 kHz

Sensitivity: FM; 1.6μv/50mW output

(-3dB Limit Sens.)

AM; 63μV/m/50mW output

Tape Deck Section:

Frequency Range: 40-12,000 Hz (with normal tape)

40-16,000 Hz (with Metal tape)

Recording System: AC bias, AC arese

Tape Speed: 4.8 cm/s


Track System: 4-track 2-channel stereo recording and

playback


:
National RX-C20
