SPECIFICATIONS
RADIO FREQUENCY RANGE: MW; 525~1610 kHz
FM; 88~108 MHz
POWER REQUIREMENT: AC; 100~110/115~127/200~220/230~250V, 50/60 Hz.
Power consumption; 10 W Battery; 9 V (six-Panasonic UM-1 R20 size dry batteries)
Car/boat battery; with optional car/boat adaptor RP-917
POWER OUTPUT: 7.0 W (3.5 Wx2 ) ...RMS (max.)
SPEAKER: 12cm (5") PM dynamic speaker
3 cm (1½") PM dynamic speaker
FREQUENCY RANGE: 50~10,000 Hz
RECORDING SYSTEM: AC bias, Magnet erase
TAPE SPEED: 4.8 cm/s (1 7\8 ips)
PROGRAM TIME: 1 hour with C-60 cassette tape
FAST FORWARD AND REWIND TIME: Approx. 90seconds with C-60 cassette tape
TRACK SYSTEM: 4-track 2-channel stereo recording and playback
INPUT: MIC; sensitivity 0.25 mV/applicable, microphone impedance 200~600ohms
(recommended microphone WM-2213)
LINE; sensitivity 63 mV/470 kohms DC IN; 9 V
OUTPUT: LINE; 0.36V/load impedance 50kΩ over
EXT SP; 3~8Ω HEADPHONES; 8Ω
OTHERS: REMOTE; for start and stop at hand
DIMENSIONS: 41.8cm(W) x22.9cm(H) x14.2cm(D) 16½"(W)x9"(H)x5 3/8 "(D)
