Год начала выпуска: 1977
Регион: Азия
SPECIFICATIONS
Semiconductors : 6 ICs, 30 transistors
Speakers : 16cm (6-1/2") x 2,
5cm (2") x 2Tuner section
Frequency ranges : FM 88 —
108MHz
MW 540-1600kHz
SW1 1.6-4.3MHz
SW2 4.3-11MHz
SW3 11-18.5MHz
SW4 18.5 - 26 MHz
Antennas : Telescopic antennas for SW
& FM
Ferrite core antenna for MW &SW1Tape recorder section
Track system : 4-Track 2-channel stereo
Frequency response :
40-13,000Hz (with chrome tape)
50-11,000Hz (with normal tape)
Wow & flutter : 0.09% (WRMS)
S/N ratio : 50dB
Rewind time : Within 110 sec. (C-60 cassette)
Fast forward time : Within 110 sec. (C-60 cassette)Amplifier section
Power output : Max. 9W (4.5 + 4.5W) DC
Input jacks : Mic x 2 (low impedance)
Line in x 2 (input level 130mV min., impedance; more than 100kOmh) DC in x 1
Output jacks : Ext. speaker x 2 (load impe-
dance 6Omh)
Headphones (load impedance 8Omh)
Line out x 2 (300mV, impedance; less than 10kOmh)
Power supply : DC 12V (8 "R20" batteries)
Car battery through a car battery adapter AC 240/220/110V, 50/60Hz (RC-828W) 240V, 50/60Hz (RC-828WH)
Power consumption : 19W
Dimensions : 470(W) x 273(H) x 127(D)mm
(18-1/2" x 10-3/4" x 5")
Weight : Approx. 6.4kg (14.1 lbs.)
(with batteries)
|
