Год начала выпуска: 1978
Регион: Америка
SPECIFICATION
Semiconductors: 6 ICs, 24 transistors;Diodes 23
Speakers: Woofer 25cm x1,
Mid-range 10cm x 1
Tweeter 5cm x1
TUNER SECTION
Frequency ranges: FM 88-108Mhz,
MW 540-1600kHz ,
SW1 1.6-4.3MHz,
SW2 4.3-11.0MHz,
SW3 11.0-26MHz,
Antennas: Telescopic antennas for FM & SW
Ferrite core antenna for MW
RECORDER SECTION
Track system: 2-Track monarual
Wow & flutter: 0.17% (WRMS)
S/N ratio: 52dB
Rewind time: Within 100 sec. (C-60 cassette)
Fast forward time: Within 100 sec. (C-60 cassette)
AMPLIFIER SECTION
Power output: Max. 14Watts 10 Watts at 10% THD
Input jacks: Mic x 1 (low impedace)
DC in x 1
Output jacks:
Earphone (load impedance 8Ω)
Power supply: DC 12V (UM/SUM-1 "D" size 8 "R20" cells)
Car battery through a car battery adapter AC
240/220/110 V, 50/60 Hz 30W
Dimensions: 49.8(W)x35.6(H)x15.6(D)cm
Weight: 7. 8kg with batteries
|
